MSP 315-4
The MSP 315-4 is an HDBaseT extender set (transmitter and receiver) that sends HDMI video over a single Cat5e or Cat6a cable. It suits installers who need to run 1080p up to 70 m or 4K at 30 Hz up to 40 m, with remote powering from one end.
- HDBaseT extender, TX and RX supplied as a set
- 1080p up to 70 m, 2160p@30Hz up to 40 m
- Runs over Cat5e or Cat6a cable
- HDMI 1.4 input, HDCP 2.2 compliant
- PoE powers one end remotely
- Bi-directional IR and RS232 pass-through
Foto
8Annunci
Ancora nessun annuncio di questo modello
Quando qualcuno venderà un MSP 315-4, qui compariranno gli annunci e lo storico delle vendite.
Vendine uno ugualeDescrizione
The MSP 315-4 carries HDMI signals between a transmitter (TX) and a receiver (RX) over one twisted-pair network cable. Full HD 1080p signals can travel up to 70 m, while 2160p at 30 Hz is supported up to 40 m. The unit accepts HDMI 1.4 signals and is HDCP 2.2 compliant.
Power over Ethernet is available, so only one end needs a power supply and the other is fed through the cable. Besides video, the link passes IR and RS232 control in both directions, which allows remote control of sources and displays across the run.
The extender is supplied as a matched TX and RX pair that is ready to use. A specification document (version 1.3, dated 2022-10-26) is offered for download from the maker's downloads tab.
Specifiche
- Marca
- RGBlink
- Modello
- MSP 315-4
- Categoria
- Audio live › Altro audio live
Video
- Extension type
- HDBaseT 4K Extender
- Maximum resolution
- Up to 2160p@30Hz
- 1080p transmission distance
- Up to 70 m
- 2160p@30Hz transmission distance
- Up to 40 m
- HDMI version
- HDMI 1.4
- HDCP
- HDCP 2.2 compliant
Connectivity
- Transmission cable
- Cat5e or Cat6a
- Video interface
- HDMI
- IR
- Bi-directional
- RS232
- Bi-directional
Power
- Power over Ethernet
- Powered from one end via PoE
- Remote powering
- One end powers the other, no second power supply needed
In the box
- Units
- Transmitter (TX) and Receiver (RX) set
- Documentation
- Specification, EN, V1.3, 2022-10-26
General
- Model
- MSP 315-4
- Series
- MSP Series, Signal Extender
